MT4017
40A MPPT solar charge controller
MPPT, 40A, 24V/48V auto,
1000/2000W max input power, 170V@-20℃；155V@25℃ max solar voltage,
LCD display, common negative, RS485
Bluetooth optional
- 12/24/36/48V automalic recognition
- Optional APP version for Bluetooth communication
- Real-lime energy slatistics funclion
- Perfect EMC & thermal design
- A combination of multiple tracking algorithms enables tracking the maximum power point quickly and accurately
- Innovative Max Power Point Tracking(MPPT) technology, tracking efficiency >99.9%
- Full digilal technology, high charge conversion efficiency up to 98%
- LCD display design, read operating data and working condition easily
- Flexible System baltery selection: Liquid, Gel, AGM and Lithium
- Exlends baltery life through accurale remote temperature sensor
- The Controller is prolecled against over-temperature due to built-in power reduction function
- Four slages ballery charging process: MPPT, boost, equalization, float
- Dual automatic protection to avoid exceeding the raled charging power and current
- Multiple load control modes: Aiways on, Street lamp, User-defind Mode
- Two USB interfaces(only -EU model)
- lOT Wireless communication or Bluetooth communication functions optional
- With the wireless communicalion function of the lOT , the controller can be connected remotely through loT'GPRS
- Monthly charging data can be calculated and displayed by grouping and graphs
- Based RS-485 standard Modbus protocol with R.11 interface lo maximize the communication needs of different occasions.
- Full automatic electronic protect funclion for increased charge controller availability
